VERTICAL MULTI-TASK MACHINING CENTER


mch-500


SPECIFICATIONS
MODEL DMT-500
TRAVEL
X-axis travel (Table forw./fackw.) 1000  mm
Y-axis travel (Spindle head rightw./leftw.) 800 mm
Z-axis travel (Spindle head upw./downw.) 950 mm
B-axis travel (Spindle head tilts) 150°  ( -30°  ~  +120° )
C-axis travel (Table rotation) 360° ( Continuous )
B-axis rotation center to table center ( X-axis at home position ) 990 mm
B-axis rotation center to table center ( at limit end ) -10 mm
Spindle nose to table center line ( B-axis at 90; X-axis at home position ) 675 mm
B-axis rotation center to table surface 150 ~ 1100 mm
Spindle nose to table ( B-axis at 0 ) -165 ~ 785 mm
CAPACITY
Table diameter Ø500  mm
Max. turning diameter (O.D.) Ø730  mm
Max. workpiece sizes Ø730  mm  x 950 mm
Max. table load 800 kgf
C-axis
Max. speed of turning shaft (rpm) 600 rpm
Rapid traverse ( C-axis ) 50 rpm
Min. indexing angle ( C-axis ) 0.0001°
SPINDLE
Max. spindle speed 12,000 rpm
Spindle nose taper KM 63
Spindle speed range 0 ~ 12,000 rpm
B-axis rapid traverse 50 rpm
Min. indexing angle ( B-axis ) 0.0001°
FEED RATE
X / Y / Z -axis rapid traverse 30 m / min
Tool shank KM 63
Tool storage capacity 40 (60)
Max. tool diameter / length / weight Ø100 mm / 300 mm / 7kgf
Max. tool diameter ( no adjacent tool ) Ø130 mm
Tool selection Random
Tool change time ( chip to chip) 3 sec
MOTORS
Spindle motor (Cont. / 30 min) 11 / 15 kw
Servomotor ( X / Y / Z / B / C ) 7 / 7 9 / 4.2 / 9.8 kw
INSTALLATION REQUIREMENT
Power required 75 KVA
Air flow required 100 L / min
TANK CAPACITY
Coolant tank capacity 120 L
Flush fluid tank 380 L
MACHINE SPACE AND WEIGHT 　
Floor space 3040 x 4640 mm
Machine weight 14500 kgf
STANDARD OPTIONS
Spindle cooling device ATC 60 tools storage
Heat exchange Flat type chip conveyor
Removable type manual pulse generator Coolant through spindle with filter
X. Y. Z. B. C. linear scale Automatic workpiece measuring device
Coolant around spindle 15,000 rpm built-in spindle
Coolant tank
Spiral type chip conveyors
Automatic power off
Call light
Work light
Tool kit & tool box

Specifications are subject to change without prior notice.
